WAMGROUP MBF - Page 89

12.13
EXT.096.--.M.4L
2
SBB
-
-
-
-
:,5,1*',$*5$0&2'(
KURZBEZEICHNUNG STROMLAUFPLAN
(175e(&Æ%/($/,0(17$7,21(/(&7
SIGLA SCHEMA ELETTRICO
4W\
Menge
4Wp
Q.tà
'(6&5,37,21
BENENNUNG
'e6,*1$7,21
DENOMINAZIONE
7<3(
TYP
7<3(
TIPO
0$.(
FABRIKAT
0$548(
MARCA
2
Metal ring PG21
Metallringmutter PG21
Bague en métal PG21
Ghiera metallo PG21
86626 RTA
1 mt
Grey PVC sheath 20x26mm
*UDXH39&+OOH[PP
Gaine PVC 20x26 mm grise
*XDLQD39&[PPJULJLD
PVC20GR RTA
4 mt
Flame-retardant cable 3x1
Graues flammwidriges Kabel 3x1
Câble antifeu 3x1 gris
Cavo antifiamma 3x1 grigio
3x1GR
MAN 1
Manometer 0.4 bar 1/8
Manometer 0,4 bar 1/8"
Manomètre 0,4 bar 1/8
Manometro 0.4 bar 1/8"
0.4 bar 1/8 WIKA
REG 1
Pressure regulator
Druckregler
Régulateur de pression
Regolatore di pressione
MRBIT 1/4-0.4 METAL WORK
REG 1
Pressure regulator support
Bügel für Druckregler
Étrier pour régulateur de pression
Staffa per regolatore di pressione
SF 1/4 METAL WORK
YV1 YV 2 2
Solenoid valve SOV 35 SOS OO
Magnetventil SOV 35 SOS OO
Électrovanne SOV 35 SOS OO
Elettrovalvola SOV 35 SOS OO
SOV35SOSOO METAL WORK
YV1 YV 2 2
Coil for solenoid valve
Spule für Magnetventil
Bobine pour électrovanne
Bobina per elettrovalvola
22D8-2450 METAL WORK
YV1 YV 2 2
Connector for coil
Steckverbinder für Spule
Connecteur pour bobine
Connettore per bobina
22STD METAL WORK
5
Union pipe Ø8
Wanddurchführung Rohr Ø8
Raccord passe paroi tube Ø8
Raccordo passaparete tubo Ø8
RL108 METAL WORK
4
Leak SFE 1/4
(QWOIWXQJ6)(
Évent SFE 1/4
6ILDWR6)(
SFE-1/4 METAL WORK
4
Female union 1/4 pipe Ø8
Anschluß 1/4" Rohr Ø8
Raccord femelle 1/4 tube Ø8
Raccordo femmina 1/4" tubo Ø8
RL2-8-1/4 METAL WORK
12
Union 90x8 1/4 pipe Ø8
Anschluß 90x8 1/4" Rohr Ø8
Raccord 90x8 1/4 tube Ø8
Raccordo 90x8 1/4" tubo Ø8
RL34-8-1/4 METAL WORK
1
T-Union pipe Ø8
T-Stück Rohr Ø8
Raccord en Té tube Ø8
Raccordo a T tubo Ø8
RL228 METAL WORK
3 mt
Light blue Elastolan pipe 8x6
+HOOEODXHU(ODVWRODQ6FKODXFK[
Tube Elastolan 8x6 bleu ciel
7XER(ODVWRODQ[D]]XUUR
ELASTOLAN
8x6AZ
METAL WORK

(/(&75,&31(80$7,&$&78$7256&211(&7,21
(/(.75,6&+(581'31(80$7,6&+(5$16&+/866'(5$8675$*+,/)(1
5$&&25'(0(17e/(&75,48(31(80$7,48('(6$&7,211(856
&2//(*$0(172(/(775231(80$7,&2$77,9$725,
