WarmFlow Utility U70HE - Page 12

Page 10
1.5.2 U-Series Utility – Pre-Wired (UHE) – Key Components
1. Heat Exchanger 2. Condensing Unit 3. Auto Air Vent 4. Service Door 5. ‘Dual-Safe’ Thermostat 6. Heat Exchanger Baffles 7. Service Door 8. Service Door Cover 9. Condensate Trap 10. Riello RDB 2.2 Burner 11. Heating Flow Connection 12. Heating Return Connection
1 2
12
4
5
6
7
8
9
11
3
10
Models up to 120 HE 150 HE Models
1
2
3
4
56
7
8
9
11
12
10
1. Heat Exchanger 2. Condensing Unit 3. Auto Air Vent 4. Service Door 5. ‘Dual-Safe’ Thermostat 6. Heat Exchanger Baffles 7. Service Door 8. Service Door Cover 9. Condensate Trap 10. Riello RDB 3.2 Burner 11. Heating Flow Connection 12. Heating Return Connection
