WarmFlow Utility U70HE - Components

Page 9
1.5 Components 1.5.1 U-Series Utility – Casing Components
1. Boiler Assembly 2. Top Casing (removable) 3. Rear Casing 4. Side Casing 5. Front Casing (removable)
1 2
3
45
Models up to 120 HE 150 HE Models
1. Boiler Assembly 2. Top Front Casing (removable) 3. Top Rear Casing (removable) 4. Rear Flue Casing 5. Rear Casing (removable) 6. Side Casing 7. Front Casing (removable)
1
2
3
5
7
4
6
