Page 24
2.3 Flue Options, Components & Dimensions
The use of any flue system other than that supplied or recommended by the
manufacturer will invalidate the warranty.
2.3.1 HE Low Level Balanced Flue Kit (FBF)
Comprising the following four main components.
1. Diverter Assembly
2. Extension
3. Elbow
4. Terminal End
5. Mounting Brackets
1
2
5
2
3
5
5
4
2.3.2 Plume Management Kit
Plume Management Kits are available for
our range of appliances. Please refer to the
Installation Instructions supplied with the kits.
