WarmFlow Utility U70HE - RDB 3.2 Spares

Page 68
13.2 RDB 3.2 Spares
No CODE 3748941 DESCRIPTION
1 3005795 • Gasket
2 3008637 • Flange
3 3005714 • End Ring
4 3005713 • Diffuser Disc
5 3007714 • Blast Tube Assembly
6 3006552 • Electrode Bracket
7 3007513 • Electrode Assembly
8 3008794 • High Voltage Lead
9 3008957 • Collar
10 3008876 • Pressure Gauge
11 3008839 • Air Damper Assembly
12 3008958 • Deadening
13 3008962 • Cover
14 3008646 • PE Cell
15 3005799 • Fan
16 3008955 • Nozzle Holder
17 3008960 • Capacitor 5 µF
No CODE 3748941 DESCRIPTION
18 3003602 • Connector
19 3005720 • Flexible Oil Line
20 3008964 • Motor
21 3000443 • Joint
22 3008648 • Coil-Shell and Knob
23 3008649 • Protection
24 3008652 • Control Box 535SE/LD
25 3008851 • Lead Coil
26 3008961 • Tube
27 3020475 • Pump
28 3008653 • Filter - O-Ring
29 3007582 • Needle Valve
30 3008651 • Regulator
31 3000439 • Pump Seal
32 3008963 • Kit Seals
33 3008959 • Air Intake
