WarmFlow Utility U70HE - Flues and Air Supply

Page 47
Head H(m)
ID 8mm
ID 10mm
0.5 1 2 3
35 25 15 8
100 100 70 30
0.5
30
100
3.5
6
20
1.5
20
90
Total Maximum Pipe Length (m)
4.2 Two Pipe System
For maximum pipe length and lift contact de-aerator manufacturer.
4.3 De-aerator System
