1.5.6 K-Series Kabin Pak – Casing Components
1. Boiler Assembly 2. Top Casing (removable) 3. Flue Assembly (removable) 4. Rear Flue Casing 5. Blanking Plug (removable) 6. Rear Casing (removable) 7. Side Casing 8. Front Casing (removable)
1
2
3
4
5
6
7
8
Models up to 120 HE 150 HE Models
1
2
3
4
5
6
7
8
1. Boiler Assembly 2. Top Casing (removable) 3. Flue Assembly (removable) 4. Rear Flue Casing 5. Blanking Plug (removable) 6. Rear Casing (removable) 7. Side Casing 8. Front Casing (removable)
