Mounting/Positioning
4
Loosen both screws at
the bottom of the 4iE
and remove the Back
Plate
Install square 2
3
/
4
” deep
back box with a single
mud ring (also called
plaster ring) in your
preferred thermostat
location
4iE
Step 1 - Install Back Plate
1 2
Before making any permanent xtures Warmup recommends
identifying your preferred location for the 4iE. It should be
located in an area with good ventilation. It should not be beside a
window/door, in direct sunlight or above another heat generating
device (e.g. heater or TV).
Ensure the distance from your router to the 4iE is not too great.
This will ensure the wireless connection is not subject to range or
interference issues once installed.
To Next Page
