3.6 Wärtsilä 16V31DF
MEAUXAUXDEDE
Wärtsilä 16V31DF
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
750750720750720rpmEngine speed
550550530550530kWCylinder output
VariableConstantConstantConstantConstantSpeed mode
88008800848088008480kWEngine output
2.712.712.722.712.72MPaMean effective pressure
Tier 2Tier 3Tier 2Tier 3Tier 2Tier 3Tier 2Tier 3Tier 2Tier 3IMO compliance
Combustion air system (Note 1)
16.813.216.813.216.212.816.813.216.212.8kg/sFlow at 100% load
4545454545°CTemperature at turbocharger in-
take, max.
60606060606060606060°CTemperature after air cooler (TE
601)
Exhaust gas system (Note 2)
17.414.717.414.716.214.217.414.716.214.2kg/sFlow at 100% load
14.712.214.912.213.811.814.912.213.811.8kg/sFlow at 85% load
13.311.013.810.712.810.413.810.712.810.4kg/sFlow at 75% load
9.97.79.87.59.17.49.87.59.17.4kg/sFlow at 50% load
270300270300270300270300270300°CTemperature after turbocharger
at 100% load (TE 517)
260320270350270350270350270350°CTemperature after turbocharger
at 85% load (TE 517)
270310260350260350260350260350°CTemperature after turbocharger
at 75% load (TE 517)
270330280370280370280370280370°CTemperature after turbocharger
at 50% load (TE 517)
77777kPaBackpressure, max.
985930985930948914985930948914mmCalculated exhaust diameter for
35 m/s
Heat balance at 100% load (Note 3)
848720848720816688848720816688kWJacket water, HT-circuit
15361008153610081360944153610081360944kWCharge air, HT-circuit
2592212826082144241620482608214424162048kWCharge air, LT-circuit
976816976816944784976816944784kWLubricating oil, LT-circuit
240240240240240240240240240240kWRadiation
Fuel consumption (Note 4)
(Note 5)
-7280-7280-7250-7280-7250kJ/kWhTotal energy consumption at
100% load
-7230-7350-7300-7350-7300kJ/kWhTotal energy consumption at 85%
load
-7250-7500-7430-7500-7430kJ/kWhTotal energy consumption at 75%
load
-7330-7820-7790-7820-7790kJ/kWhTotal energy consumption at 50%
load
-7128-7128-7097-7128-7097kJ/kWhFuel gas consumption at 100%
load
