Fig 18-6 Main engine arrangement, 4 x V46F (DAAE075827a)
E [mm]
1)
D [mm]
2)
C [mm]B [mm]
1)
Engine type
470019005600235012V46F
470019005900235014V46F
470019005900235016V46F
1)
Depending on the type of reduction gear.
2)
Minimum free space
Intermediate shaft diameter to be determined case by case.
18-6 Wärtsilä 46F Product Guide - a19 - 1 December 2017
Wärtsilä 46F Product Guide18. Engine Room Layout
