Setting
Used for
DEFAULT
Resetting default values
Available defaults: #1, #2, #3.
Default #1
Default #2
Default #3
START
Determining behavior
of start inputs
BUTTON
DOOR
DOOR
BREAK TANK
Changing fill behavior
OFF
OFF
OFF
RELAY 1 - ON
Wash Pump
0
0
0
RELAY 1 - OFF
47
27
107
RELAY 2 - ON
Rinse Pump/
Solenoid
49
29
109
RELAY 2 - OFF
60
40
120
RELAY 3 - ON
Cold Rinse
60
40
120
RELAY 3 - OFF
60
40
120
RELAY 4 - ON
Cycle Light,
Drain Pump
0
0
0
RELAY 4 - OFF
60
40
120
RELAY 5 - ON
Detergent Pump
0
0
0
RELAY 5 - OFF
30
30
30
RELAY 6 - ON
Rinse Aid Pump
0
0
0
RELAY 6 - OFF
30
30
30
RELAY 7 - ON
Spare
0
0
0
RELAY 7 - OFF
0
0
0
MEDIUM/ADD
Add this time to the
medium cycle
60
20
120
LONG/ADD
Add this time to the
long cycle
120
50
240
WASHES
Counts the number of cycles the timer has run. Reprogram to reset.
