Washtech XP Series - Control Panel Assembly

EXPLODED VIEW
EXPLODED VIEW
DETAIL A
DETAIL B
DETAIL C
Parts List
QTYDESCRIPTION
PART NUMBERITEM
1
M1-4/XP CONTROL PANEL
400 210841
1
SWITCH 4 WAY QUICK CONNECT
600 302692
1
Label XP/M1 Control Panel
400 701893
1
Knob Selector Switch
600 30524
4
1
Light Red 22mm 220VAC LED Stainless Steel
600 30529
5
1
Light Green 22mm 220VAC LED Stainless Steel
600 305286
2
TEMPERATURE GAUGE AG-903
600 30515
7
1
Switch Drain 22mm Maintained 2 Poles 220V Blue
600 305178
1
M4 X 10 S/S WELD STUD
600 800889
DETAIL A
DETAIL B
DETAIL C
302 10008
30/03/2017
3-A
XM/M1(4)/XP(D) CONTROL PANEL ASSY
REV
DATE DESCRIPTION REV
---
2
600 30269
3
400 70189
7-Rinse
600 30515
7-Wash
600 30515
6
600 30528
4
600 30524
5
600 30529
1
400 21084
8
600 30517
Knock Out for Drain Switch
WASH
RINSE
9
600 80088
8
600 30517
Service Manual XP3
27
Revision 1F
