Washtech XP Series - Rinse System

Parts List
QTYDESCRIPTIONPART #ITEM
1GM/GL WASH TEE400 900781
1
REED SWITCH STEM
600 301832
1
XP-4 WASH/RINSE MANIFOLD
ASSEMBLY
303 100033
2WASH/RINSE ARM600 411484
1XP-3 WASHTECH RINSE TANK
SS ASSEMBLY
303 100295
1PUMP PERISTALTIC
DETERGENT ADJUSTABLE
600 305266
1INLET SOLENOID SUPPORT12477
Parts List
QTYDESCRIPTIONPART #ITEM
10HOSE CLAMP ASS058
1
SOLENOID VALVE 1 WAY 90 DEG
33429
1
VACUUM BREAKER 1/2" ASSY
600 60053 10
1RINSE TANK SUPPORT BRKT400 2108811
2WASH/RINSE SPINDLE400 3022312
1NON RETURN VALVE600 3048713
1TEE BRACTON RINSE AID280 3000314
1PUMP PERISTALTIC RINSE AID
ADJUSTABLE
600 3048015
XP 30002
14/06/2017 1-A
XP-3 WASHTECH RINSE SYSTEM
REV
3
8 10
4
11
12
8
8
2
5
7
9
8
8
6 KW
12
A = 1050
B = 1200
C = 200
D = 800
E = 800
F = 700
6
1
15
13
14
DETERGENT PUMP
RINSE AID PUMP
A
1050
B
1200
C
200
D
800
E
800
F
700
Service Manual XP3
29
Revision 1F
