Input
Function
Comments
START-1
Light Cycle
start cycle with default time values
START-2
Medium Cycle
start cycle with MEDIUM time added to RELAY 1 – OFF
START-1, START-
2,
Heavy Cycle
starts cycle with LONG time added to RELAY 1 – OFF
START-3
Pressure Switch
While input is off, RELAY-5 (detergent pump) pulses 10 secs on / 1 sec
off*. If BREAK TANK is OFF, RELAY 2 (fill solenoid) is also switched on.
THERMO
Thermostop
While input is off, cycle count will pause 10 secs before RELAY 1 – OFF.
Cycle count will continue once this input is switched on.
DOOR SW
Door Switch
Cycle will not start unless this input is switched on.
If this input is switched off mid-cycle, all outputs will be switched off
and the cycle count will pause until this input is switched on.
Input
Function
Comments
START-1, START-
2 both on
Light Cycle
Cycle selected with default time values
START-1 - on,
START-2 - off
Medium Cycle
cycle selected with MEDIUM time added to RELAY 1 – OFF
START-1, START-
2 both off
Heavy Cycle
cycle selected with LONG time added to RELAY 1 – OFF
START-3
Pressure Switch
Same as above.
THERMO
Thermostop
Same as above.
DOOR SW
Door Switch
Switching this input on will start whichever cycle is selected.
If this input is switched off mid-cycle, all outputs will be switched off
and the cycle count will pause until this input is switched on.
Input
Function
Comments
START-1, START-
2 both on
Light Cycle
Cycle selected with default time values
START-1 - on,
START-2 - off
Medium Cycle
cycle selected with MEDIUM time added to RELAY 1 – OFF
START-1, START-
2 both off
Heavy Cycle
cycle selected with LONG time added to RELAY 1 – OFF
START-3
Pressure Switch
Same as above.
THERMO
Thermostop
Same as above.
DOOR SW
Door Switch and
Start Button
Cycling this input off and back on within 2 secs will start whichever
cycle is selected.
If this input is switched off mid-cycle, all outputs will be switched off
and the cycle count will pause until this input is switched on.
