Impression Series
®
Impression RC Series
Metered Water Softeners
For Models:
• IM-844 • IMP-844
• IM-948 • IMP-948
• IM-1044 • IMP-1044
• IM-1054 • IMP-1054
• IM-1248 • IMP-1248
• IM-1354 • IMP-1354
• IMC-835 • IMPC-835
• IMC-1035 • IMPC-1035
• IMRC-1054 • IMPRC-1054
• IMRC-1354 • IMPRC-1354

Table of Contents

Other manuals for Water Right IMP-948

Preview: Installation Instructions And Owner's Manual
Installation Instructions And Owner's Manual32 pages

Questions and Answers

  • M
    Mrs. Shelia AndersonSep 15, 2025
    Why Water Right Water Dispenser control valve doesn't regenerate automatically?
    • M
      Mark VelasquezSep 15, 2025
      If your Water Right Water Dispenser's control valve only regenerates when you press and hold the button, but not automatically, consider these possibilities: * **Bypass valve position:** Ensure the bypass handles are in the service position. * **Meter connection:** Check that the meter is properly connected to the meter connection on the PC board. * **Meter turbine:** Inspect the meter for any restrictions or debris. * **Programming:** Verify that the programming is correct. * **Meter wire security:** Ensure the meter cable wires are securely installed into the three-pin connector labeled METER. * **Meter condition:** Replace the meter if it's defective. * **PC board:** Replace the PC board if it's defective.
  • S
    shermanmeganAug 25, 2025
    What to do if Water Right IMP-948 Water Dispenser control valve only regenerates when buttons are held?
    • G
      gillespiemarilynAug 26, 2025
      If your Water Right Water Dispenser's control valve doesn't regenerate automatically unless you press and hold the correct buttons, several factors could be responsible. First, check if the bypass valve is in the bypass position and turn the bypass handles to place it in the service position. Ensure the meter is correctly connected to the meter connection on the PC board. A restricted or stalled meter turbine can also cause this issue; remove the meter and check for rotation or foreign material. Incorrect programming could be the problem, so review the settings for errors. Also, verify that the meter wire is securely installed into the three-pin connector labeled METER. If these steps don't resolve the issue, the meter or the PC board might be defective and need replacement.
  • R
    Rachel TaylorAug 26, 2025
    Why does my Water Right IMP-948 Water Dispenser regenerate at the wrong time?
    • K
      Kristin MillerAug 26, 2025
      If the control valve on your Water Right Water Dispenser regenerates at the wrong time of day, it could be due to several reasons. A power outage might have occurred; reset the time of day. If your PC board has a battery backup, it may be depleted. Also, the time of day might not be set correctly, so reset it to the correct time. The regeneration time itself might be set incorrectly, so reset that as well. Finally, the control valve might be set at immediate regeneration; check the programming and reset it to DELAYED for a delayed regeneration time.
  • S
    Stephen McdowellSep 15, 2025
    Why Water Right Water Dispenser PC board displays the wrong time?
    • E
      erinraymondSep 15, 2025
      If the PC board on your Water Right Water Dispenser isn't showing the correct time, here are a few things to check: * **Outlet Usage:** Make sure the power adapter is plugged into an outlet that isn't controlled by a light switch. * **Breaker/GFI:** Check and reset the breaker switch or GFI switch if it has tripped. * **Power Outage:** Reset the time of day after a power outage. If your PC board has a battery backup, it might be depleted. See the front cover and drive assembly drawing for instructions. * **Defective PC Board:** If none of the above work, the PC board might be defective and need replacement.
  • B
    Brandi NelsonSep 23, 2025
    What causes residual regenerant in Water Right IMP-948 service water?
    • E
      Eric WellsSep 23, 2025
      If residual regenerant is being delivered to the service in your Water Right Water Dispenser, check the following: * **Water Pressure:** Ensure the incoming water pressure remains at a minimum of 25 psi. * **Injector:** The injector might be incorrect, damaged, or restricted. Replace it with the correct size for your application. * **Drain Line:** Inspect the drain line for any restrictions or debris and clean it.
  • R
    Rachel GainesSep 5, 2025
    How to troubleshoot no display on Water Right Water Filtration Systems?
    • H
      hillaliciaSep 5, 2025
      If your Water Right Water Filtration System displays no image on the PC board, it could be due to several reasons: * There's no power at the electrical outlet. Solution: Repair the outlet or use a working one. * The control valve power adapter isn't plugged in. Solution: Plug the power adapter into the outlet, or connect the power cord to the PC board connection. * There's an improper power supply. Solution: Verify the correct voltage is being supplied to the PC board. * The power adapter is defective. Solution: Replace the power adapter. * The PC board itself is defective. Solution: Replace the PC board.
  • A
    Alexander JonesSep 8, 2025
    Why Water Right Water Filtration Systems control valve fails to draw in regenerant?
    • M
      Michelle GriffithSep 8, 2025
      If your Water Right Water Filtration System's control valve fails to draw in regenerant, it could be due to: * A plugged injector. Solution: Remove the injector and clean or replace it. * A faulty regenerant piston. Solution: Replace the regenerant piston. * A regenerant line connection leak. Solution: Inspect the regenerant line for an air leak. * A drain line restriction or debris causing excess back pressure. Solution: Inspect the drain line and clean it to correct the restriction. * A drain line that's too long or too high. Solution: Shorten the length and/or height. * Low water pressure. Solution: Check the incoming water pressure – it must remain at a minimum of 25 psi.
  • L
    Lisa PierceNov 23, 2025
    Why is my Water Right Water Dispenser delivering hard water?
    • J
      Jonathan ContrerasNov 23, 2025
      If your Water Right Water Dispenser is delivering hard or untreated water, consider the following potential causes. The bypass valve may be open or faulty; ensure it's fully closed or replace it. High water usage can exhaust the media; check program settings for abnormal usage. The meter might not be registering; remove it and check for rotation or obstructions. Water quality fluctuations may also be a factor; test the water and adjust program values. Additionally, check the regenerant tank for sufficient regenerant and add if necessary. If the control fails to draw in regenerant, refer to Troubleshooting Guide number 12. Also, ensure there's enough regenerant in the tank and check the refill flow control for any restrictions, replacing it if needed. Damaged seals, stack assembly, or pisto...
  • M
    maryschwartzAug 30, 2025
    Why is the time of day flashing on my Water Right Water Dispenser?
    • B
      Barbara WaltersAug 30, 2025
      If the time of day is flashing on and off on your Water Right Water Dispenser, it's likely due to a power outage. Reset the time of day. If the PC board has a battery backup, it may be depleted.
  • N
    Nicole SimmonsAug 31, 2025
    Why is my Water Right Water Dispenser delivering residual regenerant?
    • N
      Nicole LiuAug 31, 2025
      If residual regenerant is being delivered to the service in your Water Right Water Dispenser, it could be due to several reasons. Low water pressure might be the cause; check that the incoming water pressure remains at a minimum of 25 psi. The injector might be incorrect, damaged, or restricted; replace it with the correct size for your application. A restricted drain line could also be the issue; check for any obstructions and remove them.

Summary

Pre-Installation Instructions for Dealers

Installer & Homeowner Guidance

Guidance for installers and homeowners on initial setup and operational references.

Double Regeneration Procedure

Step-by-step instructions for initiating two regeneration cycles within a 24-hour period.

Bypass Valve Operation

Bypass Valve Positions

Detailed descriptions of Normal, Bypass, Diagnostic, and Shut Off positions for the bypass valve.

Installation Guidelines

Warnings & Site Requirements

Essential safety warnings and site requirements for proper installation of the water softener unit.

Plumbing, Grounding & Drain Lines

Instructions for plumbing connections, grounding, and drain line setup with anti-siphon protection.

Brine Tank & Overflow Connections

Guidelines for connecting the brine tank safety float and the overflow line to the drain.

Programming & Configuration

Setting Time of Day

Step-by-step guide for setting the current time on the control valve after power loss.

Unit Programming Parameters

Configuration steps for water hardness, regeneration days, and regeneration time settings.

System Startup Procedures

Flushing, Conditioning & Sanitizing

Steps to flush the system, condition the media, and sanitize the unit after installation.

Operating Displays & Maintenance

System Displays & Regeneration Overview

Explanation of system displays, regeneration modes, and manual control procedures.

Power, Errors & Tank Maintenance

Procedures for power loss, error messages, brine tank maintenance, and RC unit specifics.

Troubleshooting Guide: Display & Operation

Display and Operation Errors

Solutions for problems with the unit's display, time settings, water flow indication, and regeneration timing.

Troubleshooting Guide: Regeneration & Water Quality

Regeneration and Water Quality Issues

Diagnosing and resolving issues related to regeneration failures, water hardness, and regenerant delivery.

Troubleshooting Guide: Drain & Motor Control

Drain Line and Motor Control Errors

Addressing problems with water running to the drain and control valve motor movement sensing errors.

Troubleshooting Guide: Motor Timing & Park Position

Motor Timing and Park Position Errors

Troubleshooting motor timing, park position, and related component errors for the control valve.

Troubleshooting Guide: Specific Errors & Leaks

Specific Error Codes and Leak Detection

Resolving specific error codes and identifying solutions for detected leaks in the system.

Replacement Parts: Front Cover & Drive

Front Cover & Drive Assembly Parts

List of replacement parts for the front cover and drive assembly of the water softener unit.

Replacement Parts: Piston Assembly

Piston Assembly Components

Detailed list of replacement components for the piston assembly.

Replacement Parts: Valve, Elbow & Wrench

Valve, Elbow, and Service Wrench Parts

Replacement parts for bypass valve, brine elbow, check valve, and service wrench.

Replacement Parts: Injector & Meter

Injector and Meter Assembly Parts

Replacement parts for injector assemblies and the water meter and meter plug.

Replacement Parts: Drain Line Assemblies

Drain Line Assembly Parts

Replacement parts for 3/4" and 1" drain line assemblies, including DLFCs.

Replacement Parts: Brine Tank & Float

Brine Tank and Safety Float Parts

Replacement parts for the brine tank assembly and the safety float brine elbow.

Replacement Parts: Cabinet & Brine Tank

Cabinet and Brine Tank Components

Replacement parts for the water softener cabinet and brine tank components.

Installation Fitting Assemblies

PVC & Brass Fitting Assemblies

Various PVC and brass fitting assemblies for connecting the water softener system.

Shark Bite & Guest Elbow Fittings

Assortment of Shark Bite and John Guest elbow fitting assemblies for plumbing connections.

Technical Specifications

Model Specifications (IM;IMC & IMRC)

Detailed technical specifications including capacity, flow rates, pressure, and dimensions for IM/IMC and IMRC models.

Cycle Times & Usage Data

Data on typical cycle times and water usage for different softener models.

Water Softener Limited Warranty

Quick Reference Guide

System Operation & Settings Overview

Quick guide to general operation, setting time, bypass valve use, and adjusting key parameters.

Manual Regeneration Procedure

Instructions for initiating a manual regeneration cycle for immediate or same-night operation.

Water Right IMP-948 Specifications
