Water Right IMP-1354 - User Manual

Other manuals for Water Right IMP-1354

Installation Instructions And Owner's Manual32 pages

Questions and Answers

F
fdavisSep 9, 2025
Why Water Right Water Dispenser control valve doesn't regenerate automatically?
- J
  Joseph CastilloSep 10, 2025
  If your Water Right Water Dispenser's control valve only regenerates when you press and hold the button, but not automatically, consider these possibilities: * **Bypass valve position:** Ensure the bypass handles are in the service position. * **Meter connection:** Check that the meter is properly connected to the meter connection on the PC board. * **Meter turbine:** Inspect the meter for any restrictions or debris. * **Programming:** Verify that the programming is correct. * **Meter wire security:** Ensure the meter cable wires are securely installed into the three-pin connector labeled METER. * **Meter condition:** Replace the meter if it's defective. * **PC board:** Replace the PC board if it's defective.
V
velezmelissaAug 25, 2025
What to do if Water Right IMP-1354 control valve only regenerates when buttons are held?
- J
  Justin BarkerAug 26, 2025
  If your Water Right Water Dispenser's control valve doesn't regenerate automatically unless you press and hold the correct buttons, several factors could be responsible. First, check if the bypass valve is in the bypass position and turn the bypass handles to place it in the service position. Ensure the meter is correctly connected to the meter connection on the PC board. A restricted or stalled meter turbine can also cause this issue; remove the meter and check for rotation or foreign material. Incorrect programming could be the problem, so review the settings for errors. Also, verify that the meter wire is securely installed into the three-pin connector labeled METER. If these steps don't resolve the issue, the meter or the PC board might be defective and need replacement.
G
gpaulAug 26, 2025
Why does my Water Right IMP-1354 regenerate at the wrong time?
- C
  Christina AcostaAug 26, 2025
  If the control valve on your Water Right Water Dispenser regenerates at the wrong time of day, it could be due to several reasons. A power outage might have occurred; reset the time of day. If your PC board has a battery backup, it may be depleted. Also, the time of day might not be set correctly, so reset it to the correct time. The regeneration time itself might be set incorrectly, so reset that as well. Finally, the control valve might be set at immediate regeneration; check the programming and reset it to DELAYED for a delayed regeneration time.
M
martintammySep 23, 2025
What to do if Water Right Water Dispenser control valve fails to draw in regenerant?
- L
  Lindsey CoxSep 23, 2025
  If the control valve on your Water Right Water Dispenser fails to draw in regenerant, consider these possible causes: * The injector may be plugged: Remove and replace the injector. * The regenerant piston may be faulty: Replace the regenerant piston. * There may be a leak in the regenerant line connection: Inspect the regenerant line for air leaks. * The drain line may have a restriction or debris causing excess back pressure: Inspect the drain line and remove any restrictions. * The drain line may be too long or too high: Shorten the length and/or height. * The water pressure may be low: Check the incoming water pressure, ensuring it remains at a minimum of 25 psi.
T
Tami TurnerSep 10, 2025
Why Water Right Water Dispenser PC board displays the wrong time?
- A
  Andrew HardySep 10, 2025
  If the PC board on your Water Right Water Dispenser isn't showing the correct time, here are a few things to check: * **Outlet Usage:** Make sure the power adapter is plugged into an outlet that isn't controlled by a light switch. * **Breaker/GFI:** Check and reset the breaker switch or GFI switch if it has tripped. * **Power Outage:** Reset the time of day after a power outage. If your PC board has a battery backup, it might be depleted. See the front cover and drive assembly drawing for instructions. * **Defective PC Board:** If none of the above work, the PC board might be defective and need replacement.
R
ricepaulaSep 14, 2025
What causes residual regenerant in Water Right IMP-1354 Water Dispenser service water?
- H
  hcamposSep 14, 2025
  If residual regenerant is being delivered to the service in your Water Right Water Dispenser, check the following: * **Water Pressure:** Ensure the incoming water pressure remains at a minimum of 25 psi. * **Injector:** The injector might be incorrect, damaged, or restricted. Replace it with the correct size for your application. * **Drain Line:** Inspect the drain line for any restrictions or debris and clean it.
S
Sandra JohnsonSep 2, 2025
How to troubleshoot no display on Water Right Water Filtration Systems?
- B
  bryantjimmySep 2, 2025
  If your Water Right Water Filtration System displays no image on the PC board, it could be due to several reasons: * There's no power at the electrical outlet. Solution: Repair the outlet or use a working one. * The control valve power adapter isn't plugged in. Solution: Plug the power adapter into the outlet, or connect the power cord to the PC board connection. * There's an improper power supply. Solution: Verify the correct voltage is being supplied to the PC board. * The power adapter is defective. Solution: Replace the power adapter. * The PC board itself is defective. Solution: Replace the PC board.
D
Dr. Donald HarrisonSep 4, 2025
Why Water Right Water Filtration Systems control valve fails to draw in regenerant?
- G
  Grace SmithSep 5, 2025
  If your Water Right Water Filtration System's control valve fails to draw in regenerant, it could be due to: * A plugged injector. Solution: Remove the injector and clean or replace it. * A faulty regenerant piston. Solution: Replace the regenerant piston. * A regenerant line connection leak. Solution: Inspect the regenerant line for an air leak. * A drain line restriction or debris causing excess back pressure. Solution: Inspect the drain line and clean it to correct the restriction. * A drain line that's too long or too high. Solution: Shorten the length and/or height. * Low water pressure. Solution: Check the incoming water pressure – it must remain at a minimum of 25 psi.
C
Chase MillerAug 29, 2025
Why is the time of day flashing on my Water Right IMP-1354 Water Dispenser?
- A
  Amanda WashingtonAug 29, 2025
  If the time of day is flashing on and off on your Water Right Water Dispenser, it's likely due to a power outage. Reset the time of day. If the PC board has a battery backup, it may be depleted.
H
Holly StewartAug 29, 2025
Why is my Water Right IMP-1354 delivering residual regenerant?
- M
  mary96Aug 29, 2025
  If residual regenerant is being delivered to the service in your Water Right Water Dispenser, it could be due to several reasons. Low water pressure might be the cause; check that the incoming water pressure remains at a minimum of 25 psi. The injector might be incorrect, damaged, or restricted; replace it with the correct size for your application. A restricted drain line could also be the issue; check for any obstructions and remove them.
