CUBE Manual Page 42 - Revision: 5-24-2017
CUBE PARTS LIST
No WLCP Part No. Description Part No Stocked?
Consumables
1 HT-0001-I00 Hot Tank 1.3 liter 120V/500W HT-0001-I00 Yes
2 FW-0008-L00-00 Spiral Quartz FW-0008-L00-00 Yes
3 NA
10” Sediment 20 Micron Filter
Assembly with Housing CLICK
IN CLICK OUT
*Filter Element Only Part
Number: FT-0064
FT-0003-L00-00 No
4 10-8075 13W UV Lamp Assembly CT-2090-C Yes
Recommended Spare Parts
5 12-5665
Solenoid Valve with Terminal at
Outlet Position
Recommend Stocking 2 each
per every 10 units purchased
PU-4164-L00-00 Yes
6 12-1500
Solenoid Valve DC24V 1000mm
Recommend Stocking 2 each
per every 10 units purchased
PU-4016 Yes
Remaining Parts
7 NA Electronics Cover PL-1384 No
8 NA Power Transformer EL-0016-L00-00 No
9 NA CICO Filter Bracket FT-0008-L00-00 No
10 NA
JG Reducing Straight Connector
5/16-1/4(PI201008S
PU-0005-I00-00 No
