WaterLogic CUBE FIREWALL - Page 43

CUBE Manual Page 43 - Revision: 5-24-2017
11 10-3062
JG LLDPE Tube - Blue 8mm John
Guest P/N PE-0806-100M-B
PU-4014 Yes
12 10-7040
Silicon Tube 5/16" for hot
water
PU-4064 Yes
13 NA Upper Shelf PL-1385 No
14 NA Key and Display PCB EN-6141 No
15 NA User Interface PCB Bracket PL-1394 No
16 NA User Interface Overlay Label LP-7326 No
17 NA Main PCB EN-6140-L00-00 No
18 12-8315
UV 15 W 120V/60Hz Electronic
Ballast
EN-0008-L01-00 Yes
19
Purchase from
John Guest
JG Equal Tee Connector 1/4"
(PI0208S)
PU-4011 No
20 NA Top Cover PL-1383 No
21 NA Firewall Access Cover PL-0086-L00-00 No
22 NA Fan Motor (DC 24V) CT-2094 No
23 NA Back Panel PL-1386 No
