3.
Switch off the Red Power and the Green
Heater/Compressor Switches O=OFF at the
rear of the machine and remove the power
lead from the unit.
4.
Use a Phillips-head screwdriver to remove the two screws at the
rear of the machine that secure the top panel.
5.
Remove the top panel by placing your hands on the top as shown,
and push it towards the rear of the Cube then lift to remove.
Insert your finger into the round hole of the lever, and pull the
lever up to the vertical position.
Pull the lever straight up to remove the filter assembly (some
slight force may be required)
Unscrew the filter body from the filter head by turning the base in
an anti-clockwise direction.
Pour away the excess water.
Remove the filter cartridge from the filter head as shown.
CUBE Operating, Installation, and Service Manual Page 47 - Revision: 6-23-2015
