WaterLogic WL Cube - Model and Part Designations; Specifications

MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION
CUBE
Waterlogic CUBE – Ambient, Cold, Hot, and Extra Hot
F-FWCU1-M-HCA-TT-SB-IN1
SPECIFICATIONS
ITEM
Water
¼” Quick Connect
Cold Water Temperature
Cold Water Temperature – Factory Set Point 41°F - 5°C
(Adjustable) 34° - 54° F. (1.1° - 12.2°C)
Hot Water Temperature
158° - 203° F (70° - 95°C) Programmable – Factory Set Point 87°F – 30.5C°
Recommended Service Pressure
40-60 psi (275-414 kPa) – Use Pressure Regulator
Maximum Working Pressure
60 psi (414 kPa) – Use Pressure Regulator
Environmental Temperature
35° - 100°F (2° - 37°C)
Refrigerant Gas R134a – 1.94 oz. (55 grams) - Hi (280 psi) Low (90 psi)
R134a Pressures High (230 psi), Low (90 psi)
SHIPPING SPECIFICATIONS
ITEM
Width/Depth/Height
#
14 in (356 mm), 19 in (483 mm) x 17 (432,m).
#
Weight – Dry (w/o packaging) 30 lb. (15 kg)
Shipping Information
(length x width x height)
20 in. x 22 in. x 22 in.
8 units per pallet
Shipping Weight – Dry 41 lb. (19 kg)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY 120V/60Hz 15 Amp Service
+
COMPONENT POWER (approximate) AMP DRAW (approximate)
Heater 500 Watts 4.2 Amps
Compressor 210 Watts 1.75 Amps
UV Lamp System 13 Watts 0.11 Amps
Pump 10 Watts 0.08 Amps
CUBE TOTAL 733 Watts 6.14 Amps
#CUBE is 17 in. tall and may not fit between countertops and cabinets - Check installation to ensure adequate clearance.
CUBE Operating, Installation, and Service Manual Page 7 - Revision: 6-23-2015
