CUBE WETTED PARTS LIST
No Part No. Description WLUSA Part No.
1 PU-4028 Bulkhead Connector Union ¼” * ¼” JG (PI1208S) 10-3067
2 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
3 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
4 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
5 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
6 NA Equal Tee Connector ¼” JG NA
7 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
8 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
9 PU-4017-C Hot and Cold Solenoid Valve 24V- 300mm NA
10 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
11 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
12 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
13 NA Equal Tee Connector ¼” JG NA
14 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
15 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
16 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
17 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
18, 19 NA
Hot and Cold Tank Drain Valve (consists of P/N’s CT-2031 Drain Body
Valve 5/16” and CT-2028 Drain Valve Cap 5/16”)
14-5011
20 PU-4014 Tube - Blue 8mm JG (PE-0806-100M-B) 10-3062
21 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
22 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
23 HT-0001-I00 Hot Tank 1.3 Liters 500 Watts 189°F (87°C) NA
24 CT-2093 Cold Tank 1.4 Liter NA
25 FW-0008-L00-00 Spiral Quartz NA
26 PU-4064 Silicon Tube 5/16" for Hot Water 10-7040
27 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
28 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
29 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
30 PU-4064 Silicon Tube 5/16" for Hot Water 10-7040
31 PU-4086 ¼” Stopper JG (PI0808S) NA
32 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
33 NA Equal Tee Connector ¼” JG NA
34 PU-4086 ¼” Stopper JG (PI0808S) NA
35 NA Equal Tee Connector ¼” JG NA
36 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
CUBE Operating, Installation, and Service Manual Page 60 - Revision: 6-23-2015
