Technical data
Compatible labware Refer to the OneLab Domino Catalog at
andrewalliance.com/domino-catalog
Dimensions (W x L x H) 400 x 127 x 100 mm
Weight 1.5 kg
Compatible adapters and spacers
Refer to the OneLab Domino Catalog at
andrewalliance.com/domino-catalog
*Avoid spilling liquid on the device.
Extraction+ manifold
Extraction+ pump
Operating Extraction+ pump
Power on
When the device is in Standby (plug-
ged in to a power source but turned
o), press the power button to turn on the
device.
Note: The device automatically starts
up when you plug it in to a power
source.
Power o
When the device is in its idle state (no
ongoing experiment), press the power
button for 5 seconds to turn it o.
5s
Maximum pump rate 13 L/min
Measurement range (absolute) 0–1030 mbar
Measurement accuracy TEB 25.9 mbar
Resolution 0.1 mbar
Minimum pressure at 370m 100 mbar
Compatible hose inner diameter 6 mm/1/4 inch
Relative humidity 80% at 37 °C
Maximum operating altitude 2000 m
Environment temperature operating range +4 to +37 °C
Maximum noise 60 dB (A) at 1 m
User interface Through OneLab software
Ingress protection IP20*
Dimensions (W x L x H) 200 x 200 x 275 mm
Weight 3.7 kg
External power supply Input 100–240 VAC, 1.4 A/output 24 VDC, 5 A, 120 W
Power or current rating 5 A
Overvoltage category DC port Cat I
Operating voltage 24 VDC
Network connectivity Gigabit Ethernet/WiFi 2.4 GHz and 5 GHz
Pollution degree of the intended environment Pollution degree 2
Cleaning Only with a wet tissue or isopropanol
Warranty 1 year
Certication CE, FCC, RoHS, WEEE
