Watson-Marlow 730 U - First-Time Start-Up Defaults

14.2 First-time start-up defaults
The pump is preset with operational parameters as shown in table below.
Parameter 730 default
Language Not set
Default mode Manual
Default manual speed 360rpm
Pump status Stopped
Max speed 360rpm
Direction CW
Pumphead 720R
Tube size 25.4mm
Tube material Bioprene
Flow calibration 0.92 l/rev
Flow units rpm
SG value 1
Keypad lock Disabled
Auto-restart OFF
Analog signal type mA
Analog scaling type mA
Analog min current 5mA
Analog max current 19mA
Analog min flow rate/rpm 0rpm
Analog max flow rate/rpm 360rpm
Beeper ON
Security code Not set
MemoDose flow rate Mid flow rate of chosen pumphead
MemoDose volume 100ml
Pump number baud rate 9600
Stop bits 2
Remote start/stop input High = stop
Leak detector input High = leak
Input 4 Disabled
Input 5 Disabled
Output 1 Run/stop
Output 1 - status High = run
Output 2 Direction
m-730un-en-08.1 49
