Watts Vision Wired WT-D03 User Manual

5
EN
3. First Installation
Please refer to the Quick Installation Guide.
When thermostat is started, it launch is
initialization procedure:
All segment of the LCD screen are displayed
The led is blinking white
LCD screen display the software version
Thermostat initialize its internal configuration
according to H&C signal
N
N
L
out
L
L (24V to 230V)
WATTS Controller WFC only
Heat or cool signal
Clock signal (Neutral)
1
2
3
4
1
2
3
4

Watts Vision Wired WT-D03 Specifications

General

Brand	Watts
Model	Vision Wired WT-D03
Category	Thermostat
Language	English
