Wavecom Instruments Fully Integrated Test N Print Unit - User Manual
11
Operating TnP 500
Follow the simple flow chart as per the requirements.
CAUTION
Unplug all leads except power cord when you turn on the unit as unit has automatic system check feature that automatically
runs every time on unit start-up. Make sure all peripherals, such as keyboard, scanner and printer are connected before turning on.
Turn on from mains power - Connect Blue power cord and use Power On/Off switch - refer diagram on p.5
Following is for TnPB series.
[Turn on/Off from internal Battery
- Press & hold Enter button on tester till screen lights up / or till unit shuts down. Unit will operate
from internal 97.92Wh 6800mAh lithium ion battery and can perform range of safety tests. Meter Mode®, Leakage tests and RCD test
can only be performed while connected to mains due to obvious reasons.
Switch from Battery to mains - Simply connect to mains and turn on power on-off switch on tester, unit will operate from mains and
will charge the internal battery and wireless scanner battery automatically. Turning off Power On/Off switch while connected to mains
power, will turn off the unit and stop charging internal battery.
From mains power to battery - When user disconnects power from mains, unit will get switched off. Turn unit on from battery by
pressing and holding enter button on tester.
While performing RCD tests, unit will stay on battery power while RCD trips to disconnect mains power and let user print the tag or
perform the next test, simply reset the RCD which will restore the power back to unit; unit will then swiftly move to mains power
from battery automatically without shut-down, and let user re-perform RCD Test.]
Tester starts in this mode by default
Use Keyboard, Scanner to Add user, enter site details and perform
tests, save results in onboard memory, edit/ delete previous records,
print / reprint tags and more.
search barcode by scanning / using keyboard; or create new barcode,
enter sites / user / location / equipment details [Page 12]. Once done,
keep pressing enter button to take tester to Main Test Menu A. Toggle
between Menu A and Menu B by pressing enter key.
CAUTION Press and hold of Enter
Button at New/Search Barcode
screen will turn off the unit if unit is operating from internal battery-
Press and hold F3 while turning on the unit.
This will take unit straight to Main Menu A.
Keyboard, scanner & printer are
unavailable in this mode. Quick tests
performed in Tester mode will not be saved to
memory. No details for equipment /
site/location etc will be required / recorded.
Perform quick tests - No tag-printing
Use enter button to switch between Menu A and Menu B.
While in Main Menu A, use F1, F2 & F3 to perform Class 1 test, Class 2 Test and Lead test;
While in Menu B, Use F1, F2 & F3 to perform Power test, leakage test & RCD test.
When in Test and Tag (TnT) / Memory mode, after performing test, Tag will be printed automatically and results will be saved.
When in Tester mode, only quick tests can be performed through tester buttons. Keyboard / scanner/ printer can’t be used.
To use Meter Mode®, Press and Hold F3 while in Menu A.
Meter Mode® Displays electrical parameters from a power outlet source or from the appliance under test.To exit back to menu A, press
and hold Enter as displayed on screen.
Typical use of Meter Mode® can include checking ratings & parameters of appliance and compare them with labelled ratings of
appliance.
To go to options / settings Menu, Press Enter and F2 together while in Menu A
To change Insulation Voltage, Leakage test time, Audio options, Data results screen display hold time, labels options, Barcode options,
Battery operation time-out settings.
CAUTION ‘Press and hold Enter Button’ will turn off the unit if unit is operating from internal battery – TnPB series
Test & Tag Mode / Memory Mode
To Next Page
