Instrument description
1. Function Key F1
2. Function Key F2
3. Function Key F3
4. On/Off Switch
5. TnP-500 Power Socket
6. Appliance IEC Test Socket
7. LED Light Indicators
8. Keyboard
9. Storage Area (Under Keyboard)
10. Barcode Scanner
11. Label Chute
12. Wavecom Printer
13. AS/NZS 3112 Appliance Socket
14. Enter/Return Key & Pass/Fail LED Indicator
15. LCD Results Screen
Manufacturer Recommendations
Calibration: The AS/NZS3760:2010 Standard recommends a routine calibration / verification of this unit to ensure the accuracy
of readings on a 12-monthly basis, or as prescribed under any additional local Regulatory requirements.
Note: Only Wavecom Instruments or its Authorised Service Agents are permitted to repair and Calibrate this Instrument.
Failure to perform unauthorised service or repair may void all warranties and Calibration Status.
Safety Warning
This 4th Generation TnP series of products have been designed to meet stringent safety requirements, however no device can
completely protect persons from the consequences of incorrect use.
The testing of Electrical appliances requires that extra care and caution is taken at all times to ensure personal safety.
The Manufacturer also advises that appliance testing should be conducted by a Competent and suitably trained person, as
referred to under the current Standard AS3760:2010, as well as any additional legislation or rulings in different states.
If in doubt, the manufacturer suggests the user contact their responsible Authority.
For maximum safety, always ensure that the following advice is followed:
The equipment being tested is in good condition / visual check.
All user instructions are followed.
Double check power supply connections. (note LED status)
Always use specified fuses and protection devices.
Do not use leads that require repair or are damaged.
If you are unsure, call a licensed Engineer/Electrician.
* See P.6 AS/NZ 3760:2010 def.
Fully Integrated Test N Print Unit 10A ver. shown
