Appendix A Installation Drawings
WU017834 Rev. 05 July 2023 Wayne Fueling Systems | Dover Fueling Solutions 97
Junction Box Terminal Strip Wiring - Suction
Terminal Color Connection
Product
Designation
1 Black AC HOT Main Conduit
2 Red PUMP 1- HOT
Side Conduit3 Brown PUMP 2- HOT
4 Black PUMP 3- HOT
5 White NEUTRAL Main Conduit
6 White/Red PUMP 1- NEUTRAL
Side Conduit
7 White/Brown PUMP 2- NEUTRAL
8 White/Black PUMP 3- NEUTRAL
9 Brown CAT TX / RX +
10 Violet CAT TX / RX -
11 Yellow Current Loop 1 +
12 Violet Current Loop 2 -
Green/Yellow Ground Main Conduit
3X Green/Yellow Ground Side Conduit
option NC Orange Wayne TRAC TX / RX +
Main Conduit
option NC Blue Wayne TRAC TX / RX -
option NC Black
Lighted Valance
(Optional) HOT
option NC White
Lighted Valance
(Optional) NEUTRAL
option NC Blue Intercom Speaker +
option NC White Intercom Speaker -
option NC Blue Call Button +
option NC Blue Call Button -
To Next Page
