Electrical diagrams
28
8.4 Premium TECC V3, 1 and 2 compressors
SW
WS
SW
RT
SW
RT
GE
GE
Fuses:
F1 PCB 315mA (115V 630mA)
F2 fan 6.3A
F3 valve 3.15A
F4 pump 1 SW 3.15A
F5 pump 2 CW 3.15A
Cable colours
bl
br
ge
gn
gr
rt
sw
ws
blue
brown
yellow
green
grey
red
black
white
Relay Comp. 1
Blower
115/230V AC
switch board
Pressure switches
Display
External air temp.
sensor
Chilled water temp.
sensor
fan
valve
pump 2
Capacitor and
resistor pump 2 *)
*) In case a relay is used, the controller
should be without related capacitor and
resistor
Capacitor and
resistor pump 1 *)
pump 1
fan N
valve N
pump 1 N
pump 2 N
Not used
4-way rev. valve
Relay Comp. 2
4-way rev. valve
Seawater pump
Chilled water pump
