DBW 2010 / 2016
2
General Description
203
Fig. 202 DBW 2010 heaters with sensor technology
1B
u
r
n
e
r
h
e
a
d
2
I
gnition spar
k generator
3
Coolant, outlet
4
Temperature s
ensor *
5
Thermal fuse *
6
Temperature limiter *
7H
e
a
t
e
x
c
h
a
n
g
e
r
8E
x
h
a
u
s
t
o
u
t
l
e
t
9
Control unit
*
for components installed in accordance with the
heater varian
t
