Intelligent Fast-Charging System GSE Installation Guide for the DVS300/330/400 and MVS330/400
31504-76-0101
Reference National Electrical Code. ANSI/NFPA 70.1999
Table 3 DVS330 Input and Output Power Characteristics
Parameter DVS330 MVS330
Input Voltage 380/400 VAC
Input Frequency 50/60 Hz
Number of Input Phases (Excluding Ground) Three
Minimum Circuit Breaker Inrush Rating 700A
Charge Port Output Voltage 0−120 VDC
Charge Port Output Current 0−250A 0−500A
Maximum Circuit Breaker Rating 70A
Input Current at Rated Output 56/54A
Minimum Input Conductor Size 4 AWG
Minimum Grounding Conductor Size 8 AWG
Minimum Input and Grounding Conductor Terminal Torque (in-lb) 65 in-lb
Maximum Output Power 33 kW
Maximum DC Bus Current 220A
Minimum DC Bus Conductor Size 3/0 AWG
Minimum DC Bus Ground Wire Size 4 AWG
