Page 10 of 40 Webasto Charging Systems, Inc.
Intelligent Fast-Charging System GSE Installation Guide for the DVS300/330/400 and MVS330/400
31504-76-0101
2. General Information
2.1. Scope
This guide is intended to provide an authorized, fully trained installation technician with the information and
guidance necessary to install safely the GSE.
Section 2.3 lists all required nonstandard tools. If parts or tools in addition to those listed in this guide are
needed to perform service; then this service is outside the scope of this guide, and WCSI should be
contacted directly for further assistance.
Training may be scheduled by contacting WCSI Customer Service at the following phone number or
e-mail address.
• 1–866–POSICHARGE (1–866–767–4242)
• info@posicharge.com
2.2. Provided Equipment
2.3. Required Nonstandard Tools
2.4. Required Reference Literature
The following document is required reference material for this installation procedure. Installation technicians
must read and understand this document before proceeding with the installation process.
Equipment Description Quantity Orderable Part Number Comments
DVS300 09030-301-NCA
DVS300 CEC 09030-301-CEC
DVS330 (EPO buttons) 09910-301
DVS400 CEC 09190-301-CEC
DVS400 NCA 09190-301-NCA
Power station CEC 1–3 06900-301-CEC Optional
Power station NCA 1–3 06900-301-NCA Optional
Power station stands 0–8 08628 Optional
Cable management pole assembly 0–16 07233 Optional
WCSI PN Title
31504-03 Intelligent Fast-Charging System Ground Support Equipment (GSE)
Operation and Maintenance Manual for the DVS300/330/400 and MVS330/400
Equipment Description Suggested Supplier Part Number
Multimeter Fluke 8060A TRMS
Bleed-down resistor (300Ω, 10W) with alligator clips WCSI ―
Hex wrench set, SAE, ⅛″ to ⅜″ ― ―
Power station diagnostic cable WCSI 06969
