Webasto Ford Focus - Page 25

25
Ford Focus / Focus C-MAX / Focus CC
1 Hose section of heat exchanger inlet
2 Engine outlet hose section
Cutting
point
Remove connection piece according to
manufacturer's instructions. Locking device
(3) must be turned counterclockwise for this
purpose.
2 Carefully saw open clamp
1 Discard hose
Preparing
coolant
1
Connection piece of heat exchanger inlet
mounted and locked
Preparing
coolant
Before connecting, fill the coolant hoses with
coolant.
1 Connection piece of heat exchanger inlet
2 Engine outlet hose section
Check routing of hoses and correct if
necessary. Fasten wiring harness of heater
unit to coolant hoses with cable tie.
Connect-
ing hoses
46
1 2
47
21 3
i
48
1
49
D
2
C
A
1
