Webasto Ford Focus - Electrical Connection on C-MAX

9
Ford Focus / Focus C-MAX / Focus CC
Electrical Connection on C-MAX
Wiring harness pass through
1
Protective rubber plug detached
Digital timer
1
Digital timer
1 Summer/winter switch, drilled hole 12 mm dia.
Wiring
harness
installa-
tion dia-
gram
for C-Max
Fuse holder, relay K3
Fastening will not be carried out until later after
reinstalling the coolant reservoir cap! When
drilling, watch components located behind!
1 Fuse holder, 4 mm dia. hole, 5.5x13 mm self-
tapping screw
2 K3 relay, 4 mm dia. hole, 5.5x13 self-tapping
screw
Wiring harness routing
Connect ground wire to negative battery pole
and positive wire to positive battery pole.
Route wiring harness
(1) to right and fasten with
cable ties as shown.
10
1
11
1
2
sw
rt
br
bl
Do not install the metering pump
cable harness until later together
with fuel pipe along the original
vehicle fuel lines on the
underbody
i
12
1 2
13
11
