Mazda 3 MPS
1311472A
2
Table of Contents
Validity
Vehicle and engine types, equipment variants as well as national specifications, which are not listed in
these installation instructions, have not been tested. Installation according to these installation
instructions may, however, be possible.
The installation location of a time switch and summer / winter switch should be confirmed with the end
customer before installation.
Manufacturer Model Type EG-BE No. / ABE
Mazda 3 MPS BK e1 * 2001 / 116 * 0234 * ...
Engine type Engine type Power in kW Engine capacity in cm³
L3 Gasoline 191 2261
Validity 2
Heater Unit / Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory Notes on the Document 4
Preliminary Work 5
Heater Unit Installation Location 5
Preparing the Electronics 6
Electrical Connections 8
Automatic air conditioning blower control 9
Remote Start Option 12
Preparing the Installation Location 13
Installing the Heater Unit 15
Exhaust System 17
Fuel Connection 18
Combustion Air 21
Water Connection for Gasoline Engines 22
Final Work 26
Operating instructions for the end customer 27
Tank Extracting Device Template 28
