DVS/GSE GSE DVS Field Service Manual
09030-78B 15 of 49
Webasto Charging Systems, Inc.
133 Chrg Vdc Port A Low Battery voltage too low for charger Y
134 Chrg Vdc Port A High Battery voltage too high for charger Y
135 BMID A Vbat Too Low Battery voltage too low for BMID K
136 BMID A Vbat Too High Battery voltage too high for BMID K
137 Tbat Too High on Port A Battery temp too high G
138 BMID Comm Fail Port A BMID link lost after charge started E, F 3.2.3
3.2.4
139 BMID Config Warning
on Port A
BMID not adequately configured for
charger usage
L 3.2.3
140 BMID Config
Mismatch on Port A
BMID data doesn’t match battery
parameters
I
3.2.3
141 BMID Failure on Port A BMID reporting a critical failure F 3.2.4
142 BMID Temp Sensor
Failure on Port A
BMID temp sensor out of valid range F
143 Vbat Mismatch on Port A BMID and terminal voltages don’t match II
144 Battery Overdischarged
on Port A
Battery excessively discharged J
145 Early Charge
Termination on Port A
Charge terminated unexpectedly AA 2.7.6
164 Invalid Pilot on Port B Battery connected with invalid pilot
circuit
JJ
165 Chrg Vdc Port B Low Battery voltage too low for charger Y
166 Chrg Vdc Port B High Battery voltage too high for charger Y
167 BMID B Vbat Too Low Battery voltage too low for BMID K
168 BMID B Vbat Too High Battery voltage too high for BMID K
169 Tbat Too High on Port B Battery temp too high G
170 BMID Comm Fail Port B BMID link lost after charge started E, F 3.2.3
3.2.4
171 BMID Config Warning
on Port B
BMID not adequately configured for
charger usage
L 3.2.3
172 BMID Config
Mismatch on Port B
BMID data doesn’t match battery
parameters
I
3.2.3
173 BMID Failure on Port B BMID reporting a critical failure F 3.2.4
174 BMID Temp Sensor
Failure on Port B
BMID temp sensor out of valid range F
175 Vbat Mismatch on Port B BMID and terminal voltages don’t match II
176 Battery Overdischarged
on Port B
Battery excessively discharged J
177 Early Charge
Termination on Port B
Charge terminated unexpectedly AA 2.7.6
