2.7.6 Charge Termination Codes
The following table should be used to interpret charge termination codes.
Table 3. Charge Termination Codes
Code Message Description
1
INVALID BATTERY VOLTAGE Fast Charge, Amphours exceeded
2
SOC OVER START LIMIT SOC too high to start a charge
3
FC AHR LIMIT Fast Charge, Amphours exceeded
4
FC BAT TEMP LIMIT Fast Charge, battery temp limit exceeded
5
FC BMID COM LOST Fast Charge, BMID communications lost
6
FC CURRENT TIME LIMIT Fast Charge, CC mode time limit exceeded
7
FC VOLTAGE TIME LIMIT Fast Charge, CV mode time limit exceeded
8
FC USER STOP Fast Charge, user stopped (stop button or disconnected)
9
SOC LIMIT REACHED Fast Charge, normal termination, FC SOC limit reached
10
FINISH CURRENT REACHED Fast Charge, normal termination, Finish current reached
11
FINISH AHR LIMIT Finish Charge, Amphours exceeded
12
FINISH BAT TEMP LIMIT Finish Charge, battery temp limit
13
FINISH BMID COM LOST Finish Charge, BMID communications lost
14
FINISH TIME LIMIT Finish Charge, CV mode time limit exceeded
15
FINISH USER STOP Finish Charge, user stopped (stop button or disconnected)
16
FULL AHR LIMIT Full/Over charge, Amphours exceeded
17
FULL BAT TEMP LIMIT Full/Over charge, battery temp limit exceeded
18
FULL BMID COM LOST Full/Over charge, BMID communications lost
19
FULL TIME LIMIT Full/Over charge, mode time limit exceeded
20
FULL USER STOP Full/Over charge, user stopped (stop button or
disconnected)
21
FULL CHARGE UNAVAIL Full/Over charge, charge window closed, stopped
22
FULL CHARGE COMPLETE Full/Over charge, completed normally
23
EQ BAT TEMP LIMIT EQ, battery temp limit exceeded
24
EQ BMID COM LOST EQ, BMID communications lost
25
EQ TIME LIMIT EQ, time limit exceeded
26
EQ USER STOP EQ, user stopped (stop button or disconnected)
27
EQ COMPLETED EQ, normally completed
