5110159D Webasto Pure 15
Fault
list
Description
There is a fault in the power connection
to the charging station, phase monitor-
ing is active, charging station charges
with reduced power.
u
Checking of the rotary field by
an authorised electrician.
F5 LED flashes red for 1s at 2s intervals, a
signal sounds for 28s and then for 2s
every 10 minutes:
There is a fault in the vehicle.
u
Re-connect the vehicle
Table3: Fault indicators and troubleshooting
NOTE
If the warning persists, contact
Webasto Charging Hotline under
00800-24274464.
Fault
list
Description
F6 LED flashes red for 0.5s at 0.5s and
3s intervals:
the supply voltage is outside the valid
range of 180 V to 270 V.
u
Checking by an authorised elec-
trician.
Table4: Fault indicators and troubleshooting
4.3 Touch control switch
(reset)
NOTE
Do not press but only touch the
touch control switch, do not wear
gloves when operating.
The touch control switch is used to acknow-
ledge faults.
Action Description
u
Touch and hold
the switch for at
least 10s.
Starts a system self-test
and resets failures.
After the fault has been
rectified, the charging
station switches back
to "standby" mode.
4.4 Key-operated switch
The key-operated switch is used for author-
isation purposes and can be turned through
90°. Turn clockwise to unlock the charging
station. Turn anticlockwise to lock the char-
ging station.
See also Fig. 4
NOTE
The key can be removed in both pos-
itions.
4.5 Start charging
NOTE
Always take into account the vehicle
requirements before charging a
vehicle.
NOTE
Park the vehicle for charging such as
to avoid strain in the charging cable.
See also Fig. 5
Action Description
u
Connect
the char-
ging
coupling
to the
vehicle.
Charging station performs system
and connection tests.
LED: is blue, turns red for about 2
seconds after connecting to the
vehicle and then either turns
green (vehicle is charging) or
flashes blue (vehicle not yet ready
for charging).
4.6 Stop charging
4.6.1 The vehicle has stopped the
charging cycle automatically
Action Descrip-
tion
u
Unlock the car if necessary.
u
Unplug the charging coup-
ling from the vehicle.
u
Lock charging coupling in
the holder of the charging
station.
LED flashes
blue at 1
second in-
tervals.
Vehicle con-
nected, not
charging.

Webasto Pure Specifications

General

Connector Type	Type 2
Protection Class	IP54
Charging Current	32 A
Input Voltage	400 V AC
Output Voltage	400 V AC
Output Current	32 A
Power	22 kW
Protection Features	Overcurrent, Overvoltage, Short Circuit, Overheating
Charging Power	22 kW
Phases	1-phase or 3-phase (depending on model)
