Webasto Pure Installation Instructions

EN
16 5110159D Webasto Pure
4.6.2 If the vehicle does not
automatically stop the
charging cycle
Action Description
u
Set key-op-
erated
switch to
"OFF" posi-
tion.
Charging cycle is stopped. LED
changes to blue and flashes at 5
second intervals. See "LED indic-
ators on page 14", operating
status N5.
Or
u
Stop char-
ging cycle
at vehicle.
Charging cycle is stopped. LED
changes to blue and flashes at 1
second intervals. See "LED indic-
ators on page 14", operating
status N4.
5 Transportation and
storage
Observe the ambient temperature for stor-
age during transportation. See "Technical
data on page 22".
Transport the charging station only when
suitably packaged.
6 Scope of delivery
Scope of delivery Amoun
t
Charging station with pre-assembled
charging cable
1
Mounting frame
1
Scope of delivery Amoun
t
Key
2
Installation kit for wall mounting
–
Wall plug (8 x 50 mm, Fischer
UXR8)
4
–
Screw (6 x 70, T25)
2
–
Screw (6 x 90, T25)
2
–
Washer (ISO 7089-8,4)
4
Operating and installation instructions
1
Table5: Scope of delivery
u
Take the charging station and the mount-
ing frame from the package.
u
Check the completeness of the delivery.
u
Check the complete delivery for damage.
7 Required tools
Tool description Amou
nt
Slot-head screwdriver 0.5x3.5mm
1
Torx screwdriver Tx25
1
Torx screwdriver Tx10
1
Drilling machine with 8 mm drill
1
Mounting tools for 8 mm plugs and
screws
1
Hammer
1
Mounting tools for electrical cables and
wire end ferrules
1
Multimeter
1
Tool description Amou
nt
EV simulator with rotary field display
1
Required when replacing the charging
cable:
Mounting tools for cable glands M16
(wrench size 20mm) and M32 (wrench
size 36mm)
1
Round file
1
Combination pliers
1
8 Installation and
electrical connection
Observe the safety information provided
here "Safety on page 11".
NOTE
In addition to these operating and in-
stallation instructions, follow and
comply with the local regulations re-
lating to operation, installation and
environmental protection.
NOTE
The Webasto Pure safety concept is
based on a power supply system that
is earthed at all times, which must al-
ways be ensured by an electrician
during installation.

Webasto Pure Specifications

General

Connector Type	Type 2
Protection Class	IP54
Charging Current	32 A
Input Voltage	400 V AC
Output Voltage	400 V AC
Output Current	32 A
Power	22 kW
Protection Features	Overcurrent, Overvoltage, Short Circuit, Overheating
Charging Power	22 kW
Phases	1-phase or 3-phase (depending on model)
