Webasto Pure Installation Instructions

EN
20 5110159D Webasto Pure
ü No vehicle connected.
u
Set key-operated switch from ON to OFF,
wait until LED indicator flashes blue 3
times.
u
Set key-operated switch from OFF to ON
(for max. 3 seconds).
u
Set key-operated switch from ON to OFF;
wait until LED indicator flashes blue once.
u
Set key-operated switch from OFF to ON
(for max. 3 seconds).
u
Set key-operated switch from ON to OFF;
wait until LED indicator flashes blue 3
times.
– When the LED indicator flashes for the
fourth time it changes to white and the
charging station automatically assumes
programming mode.
Programming mode activated
The charging station runs through two op-
tions 10 times. If no option is selected with
the key-operated switch after the charging
station has run through them 10 times, pro-
gramming mode will be deactivated auto-
matically without any changes.
9.2 Dim LED indicator (option
1)
NOTE
The LED colours blue and green can
be dimmed. The brightness of the red
warning colour can not be changed.
Programming mode activated:
The LED indicator flashes white in the fol-
lowing sequence once:
– 0.5s OFF;
– 0.5s ON;
After a four second pause the LED indicator
switches to yellow for one second:
u
Set key-operated switch from OFF to ON.
– "Dim LED indicator" function activated.
The LED indicator changes to blue and dims
in several stages from maximum to min-
imum, in 3 second intervals. After reaching
the lowest dim level the LED indicator
switches back to maximum.
NOTE
If the key-operated switch setting is
not changed from ON to OFF within
180 seconds, the original dim level
will remain unchanged and the pro-
gramming mode will be deactivated.
u
Set key-operated switch from ON to OFF.
Dim level is selected.
If the key-operated switch setting is not
changed further within 60 seconds, the se-
lected dim level will be saved and program-
ming mode deactivated.
u
Set key-operated switch back from OFF to
ON to switch to standby mode.
9.3 Deactivate charging
current limit (option 2)
NOTE
The charging current limit is only ac-
tivated in the factory for a 22 kW
variant.
NOTE
The charging current is only limited to
20 A for 1-phase charging.
NOTE
The charging current limit may only
be deactivated in compliance with na-
tional regulations and standards.
Programming mode activated:
The LED indicator flashes white in the fol-
lowing sequence once:
– 0.5s OFF;
– 0.5s ON;
– 0.5s OFF;
– 0.5s ON;
After a three second pause the LED indicator
switches to yellow for one second:
u
Set key-operated switch from OFF to ON:
– Activate "charging current limit" function.
The current setting is indicated in colour by
the LED:
Charging current limit activated = purple
Charging current limit deactivated = light
blue

Webasto Pure Specifications

General

Connector Type	Type 2
Protection Class	IP54
Charging Current	32 A
Input Voltage	400 V AC
Output Voltage	400 V AC
Output Current	32 A
Power	22 kW
Protection Features	Overcurrent, Overvoltage, Short Circuit, Overheating
Charging Power	22 kW
Phases	1-phase or 3-phase (depending on model)
