22 5110159D Webasto Pure
devices. Addressed can be obtained from
your city or local authority. Separate collec-
tion of electrical and electronic devices en-
ables re-use, material recycling or other
forms of re-utilisation of waste equipment
while also avoiding the negative effects of
hazardous substances which may be con-
tained in the devices on the environment
and for human health.
u
Dispose of packaging in corresponding re-
cycling container in accordance with na-
tional regulations.
14 Declaration of
conformity
The Webasto Pure was developed, manufac-
tured, tested and supplied in accordance
with the relevant directives, regulations and
standards for safety, EMC and environmental
compatibility.
Webasto declares that the product Webasto
Pure is manufactured and delivered in ac-
cordance with the following directives and
regulations:
– 2014 /35/EU Low Voltage Directive
– 2014/30/EU EMC Directive
– 2011/65/EU RoHS Directive
– 2001/95/EG Product Safety Directive
– 2012/19/EU Waste Electrical and Elec-
tronic Equipment Directive
– 1907/2006 REACH regulation
The complete text of the CE-declaration of
conformity is available on the download area
of http://webasto-charging.com.
QR code for documentation.
See also Fig. 10
15 Assembly
See also Fig. 11
See also Fig. 12
All dimensions specified in mm.
16 Technical data
Descrip-
tion
Data
Mains
voltage [V]
230/400 AC (Europe)
Rated cur-
rent [A]
16 or 32 (single phase or 3-phase)
Grid fre-
quency [Hz]
50
Network
types
TT / TN
EMC class Emitted interference: class B (resid-
ential, business, commercial areas)
Immunity: industrial areas
Overvoltage
category
III as per EN 60664
Protection
class
I
IP-protection
class
IP54
Descrip-
tion
Data
Protection
against
mechanical
impact
IK08
Protective
devices
A residual current circuit breaker
and line circuit breaker must be
provided on the installation side.
See "Installation and electrical con-
nection on page 16".
Fixation type Wall and base mounting (perman-
ently connected)
Cable feed Mounted on-wall or in-wall
Power sup-
ply con-
ductor cross
section
Depending on the cable and type
of installation, the minimum cable
cross-section for a standard install-
ation is:
6 mm² (for 16 A)
10 mm² (for 32 A)
Charging
cable with
charging
coupling
Type 2 according to EN 62196-1
and EN62196-2
Mains con-
nection ter-
minal
Connection cable:
– rigid (min.-max.) 2.5-10mm²
– flexible (min.-max.)
2.5-10mm²
– flexible (min.-max.) with wire
end ferrule 2.5-10mm²
Output
voltage [V]
230/400 AC

Webasto Pure Specifications

General

Connector Type	Type 2
Protection Class	IP54
Charging Current	32 A
Input Voltage	400 V AC
Output Voltage	400 V AC
Output Current	32 A
Power	22 kW
Protection Features	Overcurrent, Overvoltage, Short Circuit, Overheating
Charging Power	22 kW
Phases	1-phase or 3-phase (depending on model)
