8.3 Installation
See also "Assembly on page 22". The sup-
plied installation material is intended for
mounting the charging station on a concrete
wall or on an external stand. For installation
on a stand, the mounting material is in-
cluded in the scope of delivery of the stand.
Only use the supplied installation material to
install the mounting frame. See for an over-
view of the mounting frame.
See also Fig. 6
Legend
Mounting frame Hook to attach the
charging station
Spirit level Prepared weak spot
Weak-spots for cable leadthroughs for sur-
face mounting the connection cable.
u
Mark the 4 holes with the aid of the
mounting frame and spirit level.
– Make sure that the holes are centred.
u
Drill the 4 holes in the wall.
u
Insert the wall plugs in the holes.
u
Prepare the mounting frame for the cable
installation:
– Connection cable from rear:
feed the cable through the bottom part of
the frame.
– Connection cable from top/left/right/bot-
tom:
remove the prepared weak-spots in the
frame.
u
Place the mounting frame in level posi-
tion.
u
Secure the mounting frame with the 2
short screws and washers on the top
holes.
u
Remove the bottom cover from the hous-
ing.
See also Fig. 7
u
Feed the connection cable through the
opening in the lower part of the housing
and fix it with the rubber grommet sup-
plied in the scope of delivery.
u
Place the charging stations on the two
hooks at the top of the frame.
u
Secure the bottom part of the charging
station with the 2 long screws and wash-
ers.
8.4 Electrical connections
– The connection terminals are alligator
clips.
– Depending on the cable and type of in-
stallation, the minimum cable cross-sec-
tion for a standard installation is 6mm²
(for 16 A) and 10mm² (for 32A).
NOTE
Use wire end ferrules in case of flex-
ible connection cable.
u
Feed the connecting cable through the
rubber grommet into the centre of the
charging station housing, straight and
without tension. See also "Installation on
page 18".
u
Route the connection cable with the cor-
rect radius (approx. cable diameter x10) to
the connection terminals.
u
Cut the wires to the correct length. Keep
the connections as short as possible. The
PE conductor should be longer than all
the other wires.
u
Strip the wires to a length of 12mm.
u
Check whether the power supply is 1-
phase or 3-phase.
– 1-phase: Use only L1, N and PE.
– 3-phase: Use L1, L2, L3, N and PE. Then
measure the phase order.
NOTE
A clockwise phase order is required.
u
Secure the wires to the connection ter-
minals as illustrated.
See also Fig. 8
u
Check that the connections are tight and
connection cable is secure.
8.5 DIP switch settings
DANGER
High voltages.
u Danger of fatal electric shock.
u
Ensure safe isolation from the power sup-
ply.
