F 46 0349 M
Retrofit/Installation Kit no. 82 30 0 020 941 Date: 05.2000
Installation Instructions no. 01 29 0 021 305
14. Circuit diagram for vehicles with IHKA (automatic heating
and air conditioning) from start of production and vehicles with IHR from 9.98
EN/41
