Retrofit/Installation Kit no. 82 30 0 020 941 Date: 05.2000
Installation Instructions no. 01 29 0 021 305
If at plug-in place (1) a relay instead of plug
connector (gold-yellow) is fitted, this will have to
be replaced with a plug connector (gold-yellow).
In this case the blower regulator has to be
changed also (for part numbers see Note on
ordering).
Pull out blower relay (1) from plug base X58 and
replace it with plug connector.
4. Check state of the art of the model and if necessary change bridging
connector and blower regulator (only vehicles with IHKA
(automatic heating and air conditioning) to 9.98)
Pull off connector X671 (1) from blower regulator
(2).
Screw out TORX screws (1) of the blower
regulator (2). Change blower regulator (2).
EN/27
