ASSEMBLY
ASSEMBLY
Read and follow the assembly and adjustment instructions for your
mower. All fasteners are in the parts bag. Do not discard any parts
or material, keep extras as spares.
WARNING: Before doing any assembly or
maintenance to the mower, remove the wire from the
spark plug.
NOTE: In this instruction book, left and right describe the
location of a part with the operator on the seat.
PARTS BAG - CONTENTS
The fasteners and other loose parts are shown below. The fasteners are shown full size. The quantity is shown in brackets ( ).
2x82
(2) Carriage Bolt
1001054
(2) Knob
14x79
(2) Wing Nut
17x47
(2) Washer
690604
(1) Cover, Terminal
(2) Ignition Key
LOOSE PARTS - CONTENTS
Steering Collar
Steering Wheel
And Post
Seat
F-050603L
Instructions Pack
Hardware Pack
Side Discharge Attachment
To Next Page
