12530RideOnMower
WE12530
REPAIRPARTS
CHASSIS&HOOD
REF PARTNO DESCRIPTION REF PARTNO DESCRIPTION
1WE‐690566 Seat 22 WE‐1401240 FuelTank
2WE‐1401027E245 Hood 23 WE‐06x111 Screw
3WE‐017x47 Washer 24 WE‐26x253 Screw
4WE‐1001054 WingBolt 26 WE‐1401110 HoodPropRod
5WE‐002x53 CarriageBolt 27 WE‐1401282 SeatDeckSpring
6WE‐1401036E701 HingeBracket 28 WE‐1401352E701 ProprRodBracket
7WE‐009x29 ShoulderBolt 29 WE‐26x201 Screw
8WE‐009x56 ShoulderBolt 30 WE‐15x116 NylonLockNut
10 WE‐1401113 BatteryRod 31 WE‐1401248 ThrottleControl
11 WE‐015x84 FlangeNut 32 WE‐1401084 DetentCover
12 WE‐1401025E701 RearPlate 33 WE‐009x47 ShoulderBolt
13 WE‐26x249 Screw 36 WE‐1401145 LeftFootmat
14 WE‐1401050E701 HitchPlate 37 WE‐1401144 RightFootmat
15 WE‐1401086 Cover
39 WE‐1401298E701 Frame
16 WE‐26x263 Screw
40 WE‐1401347E245 SeatDeck
17 WE‐1401076E701 BatteryTray
41 WE‐094744 Bumper
18 WE‐015x79 FlangeNut
42 WE‐15x116 Nut
19 WE‐017x37 Washer 43 WE‐0025x2 Screw
20 WE‐0031x6 CotterPin 44 WE‐7601036 FoilHeatShieldKit
21 WE‐092317 FuelTankCap
39
