Webb 12530 - Page 41

12530RideOnMower
WE12530
REPAIRPARTS
MOTIONDRIVE
REF PARTNO DESCRIPTION REF PARTNO DESCRIPTION
1B&SEngine
37 WE‐1401078 ClutchRod
2WE‐01x134 HexBolt
38 WE‐1401128E701 ClutchArmAssembly
3WE‐1401207 HeatShieldAssembly
39 WE‐0011x7 RetainerRing
4WE‐018x32 Lockwasher
40 WE‐1401077 DrivePulley
5WE‐0025x2 Screw
41 WE‐002x53 CarriageBolt
6WE‐1401251 Muffler
42 WE‐009x39 ShoulderBolt
7WE‐091309 MufflerGasket
43 WE‐1401252 IdlerPulley
8WE‐165x75 ExtensionSpring
44 WE‐37x110 MotionDriveBelt
9WE‐165x148 ExtensionSpring
45 WE‐1401066 SplitStackPulley
10 WE‐015x88 Nut
46 WE‐019x35 StarWasher
11 WE‐26x249 Screw
47 WE‐17x170 Washer
12 WE‐1401068E701 TransaxleLHBracket
48 WE‐01x140 HexBolt
13 WE‐015x84 FlangeNut
49 WE‐17x102 Washer
14 WE‐021544 PedalCover
50 WE‐1401031E701 RearArm
15 WE‐0031x4 CotterPin
51 WE‐1401039E701 RearHangerBracket
16 WE‐017x53 Washer
52 WE‐094067 ThreadedShoulderPin
17 WE‐030x20 CotterPin
53 WE‐01x155 HexBolt
18 WE‐1401127E701 PedalAssembly
54 WE‐01x120 Bolt
19 WE‐1401112 ParkingBrakeRod
55 WE‐1401051E701 TorqueReatorBracket
20 WE‐091079 ParkingBrakeRodGrip
56 WE‐06x105 Screw
21 WE‐1401298E701 Frame
57 WE‐017x38 ShiftYokeWasher
22 WE‐094198 ShiftLeverGrip
58 WE‐1401260E701 ReinforcementPlate
23 WE‐1401148 AdjustingNut
59 WE‐1401351Z ShiftYoke
24 WE‐1401122 ShiftLink
60 WE‐17x148 Washer
25 WE‐1401355 ShiftLever
61 PeerlessTransaxle
26 WE‐1401032E701 LiftPivotBracket
62 WE‐1401042E701 TransaxleRHBracket
27 WE‐165x147 ExtensionSpring
64 WE‐17x160 Washer
28 WE‐009x39 ShoulderBolt
65 WE‐056534 SquareKey
29 WE‐1401043E701 PivotBracket
66 WE‐1401103ZRearWheelSpacer
30 WE‐1401104 ShortBeltGuide
67 WE‐1401120 Rear15"Wheel
31 WE‐1401105 LongBeltGuide
68 WE‐094618 HubCap
32 WE‐1401057E701 BeltGuidePlate
69 WE‐0011x3 E‐Ring
33 WE‐0025x7 Bolt
70 WE‐17x195 Washer
34 WE‐015x79 FlangeNut
72 WE‐092378 ScrewLock
35 WE‐1401059E701 SupportBracket
73 WE‐015x98 Nut
36 WE‐094815 AdjustingNut
74 WE‐015x43 Nut
