12530RideOnMower
WE12530
REPAIRPARTS
STEERING
REF PARTNO DESCRIPTION REF PARTNO DESCRIPTION
1WE‐095185 SteeringWheel 21 WE‐01x146 HexBolt
2
WE‐711326
SteeringInsert 22 WE‐011x23 E‐Clip
3WE‐1401044 SteeringConsole 23 WE‐030x35 CotterPin
4WE‐26x270 Screw 24 WE‐094131 SpringRetainer
5WE‐1401090
UpperSteering
Bearing
25 WE‐1401046E701 SteeringRack
6WE‐1401226 SteeringTube 26 WE‐17x201 Washer
7WE‐1401100 SteeringShaft 27 WE‐1401376E701 FrontAxleBracket
8WE‐1401055E701 SteeringSupport 28 WE‐17x157 Washer
9WE‐26x249 Screw 29 WE‐1401250E701
Axle&Spindle
Assembly
10 WE‐009x67 ShoulderBolt
30 WE‐1401059E701 SupportBracket
11 WE‐1401098
LowerSteering
Bearing
31 WE‐15x118 FlangeNut
12 WE‐1401102 Roller 32 WE‐1401143 FrontWheel
13 WE‐1401058E701
GearMounting
Plate
33 WE‐17x197 Washer
14 WE‐1401123E701 DragLink
34 WE‐17x157 Washer
15 WE‐015x84 FlangeNut
35 WE‐094618 HubCap
16 WE‐17x104 Washer 36 WE‐0025x3 Bolt
17 WE‐015x88 FlangeNut 37 WE‐17x146 Washer
18 WE‐01x111 HexBolt 38 WE‐1401377 RubberBumper
19 WE‐17x118 Washer 39 WE‐017x91 Washer
20 WE‐1401099 PinionGear
