12530RideOnMower
WE12530
REPAIRPARTS
MOWERHOUSING
SUSPENSION
REF PARTNO DESCRIPTION REF PARTNO DESCRIPTION
1WE‐092697 LiftLeverGrip 16 WE‐093349 GuideScrew
2WE‐1401117 LiftLever 17 WE‐015x79 FlangeNut
3WE‐165x154 ExtensionSpring 18 WE‐015x84 FlangeNut
4WE‐094137 FrictionPad 19 WE‐1401147 LeafSpring
5WE‐017x45 Washer 20 WE‐1401040E701 FrontHanger
6WE‐095004 Wingnut 21 WE‐1401116 PTOLever
7WE‐1401033E701 LiftLink 22 WE‐26x263 Screw
8WE‐1401096 SpacerTube 23 WE‐094198 PTOGrip
9WE‐0031x4 HairPin 24 WE‐1401369E701 PTOBracket
10 WE‐002x93 CarriageBolt 25 WE‐009x4 2 ShoulderBolt
11 WE‐1401030E701
FrontHangerPivot
Bracket
26 WE‐165x157 ExtensionSpring
12 WE‐1401118 FrontHangerPin
27 WE‐165x92 ExtensionSpring
13 WE‐26x249 Screw 30 WE‐1401260 ReinforcementPlate
14 WE‐1401129E701 LifterArmAssembly 31 WE‐26x267 Screw
15 WE‐17x206 Washer
