Webb 12530 - Page 47

12530RideOnMower
WE12530
REPAIRPARTS
MOWERHOUSING
REF PARTNO DESCRIPTION REF PARTNO DESCRIPTION
1WE‐37x111 BladeDriveBelt
32 WE‐009x42 ShoulderBolt
2WE‐1401092 InputPulley
34 WE‐030x20 CotterPin
3WE‐15x140 Locknut
35 WE‐1401185E701 BrakeArmAssembly
4WE‐015x98 FlangeNut
36 WE‐1401119 IdlerArmLink
5WE‐14012 52 IdlerPulley
37 WE‐0025x7 Bolt
6WE‐015x84 FlangeNut
38 WE‐1401052E701 BrakeMountingBracket
7WE‐1401031E701 RearArm
39 WE‐1401094 JackshaftSpacer
8WE‐015x79 FlangeNut
40 WE‐1401259ZIdlerMountingPlate
9WE‐009x58 ShoulderBolt
42 WE‐019x45 Washer
10 WE‐1401033E701 LiftLink
43 WE‐002x94 CarriageBolt
11 WE‐17x102 Washer
45 WE‐002x53 CarriageBolt
12 WE‐0031x4 HairPin
47 WE‐1401036E701 BladeHousing
13 WE‐094067 ThreadedShoulderBolt
48 WE‐1401106E701 MulchingCoverHinge
14 WE‐1401047E701 LeftRearBracket
49 WE‐015x88 FlangeNut
15 WE‐1401235E701 RightRearBracket
50 WE‐028x76 SpeedNut
16 WE‐1401038E701 AdjustmentPlate
51 WE‐014x86 Wingnut
17 WE‐094137 FrictionPad
52 WE‐002x74 CarriageBolt
18 WE‐017x45 Washer
53 WE‐091767Z ChuteDeflectorRod
19 WE‐095004 Wingnut
54 WE‐028x23 PushCap
20 WE‐166x43 LeftTorsionSpring
55 WE‐1401080 MulchCover
21 WE‐166x42 RightTorsionSpring
56 WE‐1401275 MandrelHousing
22 WE‐1401095 SpacerTube
57 WE‐1001035 BladeAdapter
23 WE‐1401037E701 DeckBracket
58 WE‐1401079E701 Blade
24 WE‐1401040E701 FrontHanger
59 WE‐17x166 CupWasher
26 WE‐1401065 SplinedShaft
60 WE‐17x165 Washer
27 WE‐1401258E701 IdlerArmAssembly
61 WE‐15x100 BladeMountNut
28 WE‐009x39 ShoulderBolt
62 WE‐1401081 ChuteDeflector
29 WE‐017x47 Washer
63 WE‐17x120 Washer
30 WE‐165x157 ExtensionSpring
64 WE‐0025x7 Bolt
31 WE‐166x46 TorsionSpring
WE‐7601035
CompleteMowerDeck
Assembly
47
