EXPLODED VIEW Q200
1. Lid
2. Handle Spacer
3. Handle
4. Cooking Grate
5. Igniter Electrode Assembly
6. Left Side Table
7. Right Side Table Assembly
8. Burner Tube
9. Cookbox
10. Carrying Handle
11. Rear Cradle
12. Front Cradle
13. Igniter
14. Hose Bracket
15. Disposable Drip Pan
16. Catch Pan
17. Valve, Hose and Regulator Assembly
18. Control Panel
19. Control Knob
20. Q
®
Stand Retention Clips
21. Q
®
Stand Table
22. Q
®
Stand Legs
23. Q
®
Stand Skirt Clips
24. Q
®
Stand Skirt
1
3
2
4
5
7
8
9
10
14
13
15
12
11
16
17
18
6
Q200_EURO_LP_060210
19
20
22
21
23
24
